Important Notice from HMRC Formatting of Master Unique Consignment references (MUCRs)

BY:

Niamh O'Connor
14 June 2023

SHARE:

HMRC has today, 14th June 2023, sent out an email to all export declarants who use inventory-linked maritime locations, notifying them of the correct formatting to use when inputting MUCRs in CHIEF to ensure these can be successfully linked to CDS.

HMRC says that 2,400 declarants will receive this email on Wednesday, 14th June; the remaining 1,000 declarants for whom HMRC does not hold an email address will receive a letter containing the same information in the post in the next week or two.



Communication from HMRC



You must read the email and Appendix (details below) and follow instructions, paying particular attention to bullet point 2 if you use a MUCR rather than a DUCR to arrive your goods.



IMMEDIATE ACTIONS TO TAKE TO CONTINUE EXPORTING GOODS THROUGH INVENTORY-LINKED MARITIME LOCATIONS



HMRC are writing to inform you of changes you must make if you export goods through an inventory-linked maritime location and currently complete your export declarations through the Customs Handling of Import and Export Freight (CHIEF) system.



HMRC is replacing the CHIEF system with the Customs Declaration Service (CDS). To prepare for this, community system providers (CSPs) have started partial migration to CDS, which means sending export movement and consolidation messages to CDS to be transmitted to CHIEF. These messages are then being matched with the relevant customs declarations so they can be processed and given a customs clearance status.



What do I need to do?

As a result of this change, you must take the following actions for any future export declarations and movements you submit immediately. You must do this immediately; otherwise, you may experience clearance delays on any export declarations submitted through an inventory-linked maritime location.



1)    YOU MUST NOT use Movement Reference Numbers (MRNs) as a reference for export arrival movements. Instead, you must use a Declaration Unique Consignment Reference (DUCR) or a Master Unique Consignment Reference (MUCR) if one exists.



2)    You must use the CDS Master Unique Consignment Reference (MUCR) format containing only one hyphen. You may encounter delays if you use a CHIEF MUCR format using more than one hyphen. You can find further guidance on the formatting of MUCRs in the appendix section of this letter.



Following the steps above will ensure the movement of your export goods through an inventory-linked maritime location and avoids customs clearance delays while you remain on CHIEF.





APPENDIX

Guidance on CDS MUCR formats

This is set out in Section 4.1.1 of the CDS01 Inventory Linking Exports Service Design document, and this information is reproduced below:


MUCRs

All MUCRs should consist of a maximum length of 35 characters overall.


For Air:

A:[0-9A-Z]{3}[0-9]{8}


Use “A:” followed by:

-      Three characters which must be numeric (between 0 and 9 inclusive) and/or upper-case alpha (between A and Z inclusive)

-      Followed by eight characters which must be numeric (between 0 and 9 inclusive)


For Courier:

C:[A-Z]{3}[0-9A-Z]{3,30}


Use “C:” followed by:

-      Three characters which must be upper case alpha (between A and Z inclusive)

-      Between three and thirty characters which can be numeric (between 0 and 9 inclusive) and/or upper-case alpha (between A and Z inclusive)


Other MUCR formats:

GB/[0-9A-Z]{3,4}-[0-9A-Z]{5,28}

Use “GB/” followed by:


-      Between three and four characters which can be numeric (between 0 and 9 inclusive) and/or upper-case alpha (between A and Z inclusive)

-      The next character must be a “-“

-      Between five and twenty-eight characters which can be numeric (between 0 and 9 inclusive) and/or upper-case alpha (between A and Z inclusive)


GB/[0-9A-Z]{9,12}-[0-9A-Z]{1,23}

Use “GB/” followed by:


-      Between nine and twelve characters which can be numeric (between 0 and 9 inclusive) and/or upper-case alpha (between A and Z inclusive)

-      The next character must be a “- “

-      Between one and twenty-three characters which can be numeric (between 0 and 9 inclusive) and/or upper-case alpha (between A and Z inclusive)


Current CHIEF MUCR formats are permitted, although the use of a second hyphen for “GB/” MUCRs or other non-alphanumeric characters are not accepted.
